Showing nearby places and place details using Google Places API and Google Maps Android API V2

Written by
Tutorials , , , , , , , , 1 Comment

Step 1 :- Create New Android Project.

Step 2 :- Add Google-play-services_lib to your project.

Step 3 :- Open AndroidManifest.xml file.

<!--?xml version="1.0" encoding="utf-8"?-->
package="com.mapv2.demo"
android:versionCode="1"
android:versionName="1.0" &gt;

&lt;uses-sdk
android:minSdkVersion="8"
android:targetSdkVersion="17" /&gt;

&lt;permission
android:name="com.mapv2.demo.permission.MAPS_RECEIVE"
android:protectionLevel="signature"/&gt;

&nbsp;

&nbsp;

&lt;uses-feature
android:glEsVersion="0x00020000"
android:required="true"/&gt;

&lt;application
android:allowBackup="true"
android:icon="@drawable/ic_launcher"
android:label="@string/app_name"
android:theme="@style/AppTheme" &gt;
&lt;activity
android:name="com.mapv2.demo.MainActivity"
android:label="@string/app_name" &gt;
&nbsp;

&lt;activity
android:name="com.mapv2.demo.PlaceDetailsActivity"
android:label="@string/app_name" &gt;



&lt;meta-data
android:name="com.google.android.maps.v2.API_KEY"
android:value="AIzaSyCmX7SLVHXxU9pSqb2QbAOvdnjAGUulOrk"/&gt;

&nbsp;

Step 4 :- Open activity_main.xml.

xmlns:tools="http://schemas.android.com/tools"
android:layout_width="match_parent"
android:layout_height="match_parent"
tools:context=".MainActivity" >

<Spinner
android:id="@+id/spr_place_type"
android:layout_width="wrap_content"
android:layout_height="60dp"
android:layout_alignParentTop="true" />

<Button
android:id="@+id/btn_find"
android:layout_width="wrap_content"
android:layout_height="60dp"
android:layout_alignParentTop="true"
android:layout_toRightOf="@id/spr_place_type"
android:text="@string/str_btn_find" />

android:id="@+id/map"
android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:layout_below="@id/spr_place_type"
class="com.google.android.gms.maps.SupportMapFragment" />

1.) activity_place_details.xml

<!--?xml version="1.0" encoding="utf-8"?-->
android:layout_width="match_parent"
android:layout_height="match_parent"
android:orientation="vertical" &gt;

&lt;WebView
android:id="@+id/wv_place_details"
android:layout_width="fill_parent"
android:layout_height="match_parent" /&gt;

&nbsp;

Step 5 :- Open MainActivity.java

package com.mapv2.demo;

import java.io.BufferedReader;
import java.io.IOException;
import java.io.InputStream;
import java.io.InputStreamReader;
import java.net.HttpURLConnection;
import java.net.URL;
import java.util.HashMap;
import java.util.List;

import org.json.JSONObject;

import android.app.Dialog;
import android.content.Intent;
import android.location.Criteria;
import android.location.Location;
import android.location.LocationListener;
import android.location.LocationManager;
import android.os.AsyncTask;
import android.os.Bundle;
import android.support.v4.app.FragmentActivity;
import android.util.Log;
import android.view.Menu;
import android.view.View;
import android.view.View.OnClickListener;
import android.widget.ArrayAdapter;
import android.widget.Button;
import android.widget.Spinner;

import com.google.android.gms.common.ConnectionResult;
import com.google.android.gms.common.GooglePlayServicesUtil;
import com.google.android.gms.maps.CameraUpdateFactory;
import com.google.android.gms.maps.GoogleMap;
import com.google.android.gms.maps.GoogleMap.OnInfoWindowClickListener;
import com.google.android.gms.maps.GoogleMap.OnMarkerClickListener;
import com.google.android.gms.maps.SupportMapFragment;
import com.google.android.gms.maps.model.LatLng;
import com.google.android.gms.maps.model.Marker;
import com.google.android.gms.maps.model.MarkerOptions;

public class MainActivity extends FragmentActivity implements LocationListener{

GoogleMap mGoogleMap;
Spinner mSprPlaceType;

String[] mPlaceType=null;
String[] mPlaceTypeName=null;

double mLatitude=0;
double mLongitude=0;

HashMap<String, String> mMarkerPlaceLink = new HashMap<String, String>();

@Override
protected void onCreate(Bundle savedInstanceState) {

super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);

// Array of place types
mPlaceType = getResources().getStringArray(R.array.place_type);

// Array of place type names
mPlaceTypeName = getResources().getStringArray(R.array.place_type_name);

// Creating an array adapter with an array of Place types
// to populate the spinner
ArrayAdapter adapter = new ArrayAdapter(this, android.R.layout.simple_spinner_dropdown_item, mPlaceTypeName);

// Getting reference to the Spinner
mSprPlaceType = (Spinner) findViewById(R.id.spr_place_type);

// Setting adapter on Spinner to set place types
mSprPlaceType.setAdapter(adapter);

Button btnFind;

// Getting reference to Find Button
btnFind = ( Button ) findViewById(R.id.btn_find);

// Getting Google Play availability status
int status = GooglePlayServicesUtil.isGooglePlayServicesAvailable(getBaseContext());

if(status!=ConnectionResult.SUCCESS){ // Google Play Services are not available

int requestCode = 10;
Dialog dialog = GooglePlayServicesUtil.getErrorDialog(status, this, requestCode);
dialog.show();

}else { // Google Play Services are available

// Getting reference to the SupportMapFragment
SupportMapFragment fragment = ( SupportMapFragment) getSupportFragmentManager().findFragmentById(R.id.map);

// Getting Google Map
mGoogleMap = fragment.getMap();

// Enabling MyLocation in Google Map
mGoogleMap.setMyLocationEnabled(true);

// Getting LocationManager object from System Service LOCATION_SERVICE
LocationManager locationManager = (LocationManager) getSystemService(LOCATION_SERVICE);

// Creating a criteria object to retrieve provider
Criteria criteria = new Criteria();

// Getting the name of the best provider
String provider = locationManager.getBestProvider(criteria, true);

// Getting Current Location From GPS
Location location = locationManager.getLastKnownLocation(provider);

if(location!=null){
onLocationChanged(location);
}

locationManager.requestLocationUpdates(provider, 20000, 0, this);

mGoogleMap.setOnInfoWindowClickListener(new OnInfoWindowClickListener() {

@Override
public void onInfoWindowClick(Marker arg0) {
Intent intent = new Intent(getBaseContext(), PlaceDetailsActivity.class);
String reference = mMarkerPlaceLink.get(arg0.getId());
intent.putExtra("reference", reference);

// Starting the Place Details Activity
startActivity(intent);
}
});

// Setting click event lister for the find button
btnFind.setOnClickListener(new OnClickListener() {

@Override
public void onClick(View v) {

int selectedPosition = mSprPlaceType.getSelectedItemPosition();
String type = mPlaceType[selectedPosition];

StringBuilder sb = new StringBuilder("https://maps.googleapis.com/maps/api/place/nearbysearch/json?");
sb.append("location="+mLatitude+","+mLongitude);
sb.append("&radius=5000");
sb.append("&types="+type);
sb.append("&sensor=true");
sb.append("&key=AIzaSyCfdXATlz7jtM6MEvy9Xh_3_g_Ivc5ysXE");

// Creating a new non-ui thread task to download Google place json data
PlacesTask placesTask = new PlacesTask();

// Invokes the "doInBackground()" method of the class PlaceTask
placesTask.execute(sb.toString());

}
});

}

}

/** A method to download json data from url */
private String downloadUrl(String strUrl) throws IOException{
String data = "";
InputStream iStream = null;
HttpURLConnection urlConnection = null;
try{
URL url = new URL(strUrl);

// Creating an http connection to communicate with url
urlConnection = (HttpURLConnection) url.openConnection();

// Connecting to url
urlConnection.connect();

// Reading data from url
iStream = urlConnection.getInputStream();

BufferedReader br = new BufferedReader(new InputStreamReader(iStream));

StringBuffer sb = new StringBuffer();

String line = "";
while( ( line = br.readLine()) != null){
sb.append(line);
}

data = sb.toString();

br.close();

}catch(Exception e){
Log.d("Exception while downloading url", e.toString());
}finally{
iStream.close();
urlConnection.disconnect();
}

return data;
}

/** A class, to download Google Places */
private class PlacesTask extends AsyncTask<String, Integer, String>{

String data = null;

// Invoked by execute() method of this object
@Override
protected String doInBackground(String... url) {
try{
data = downloadUrl(url[0]);
}catch(Exception e){
Log.d("Background Task",e.toString());
}
return data;
}

// Executed after the complete execution of doInBackground() method
@Override
protected void onPostExecute(String result){
ParserTask parserTask = new ParserTask();

// Start parsing the Google places in JSON format
// Invokes the "doInBackground()" method of the class ParseTask
parserTask.execute(result);
}

}

/** A class to parse the Google Places in JSON format */
private class ParserTask extends AsyncTask<String, Integer, List<HashMap<String,String>>>{

JSONObject jObject;

// Invoked by execute() method of this object
@Override
protected List<HashMap<String,String>> doInBackground(String... jsonData) {

List<HashMap<String, String>> places = null;
PlaceJSONParser placeJsonParser = new PlaceJSONParser();

try{
jObject = new JSONObject(jsonData[0]);

/** Getting the parsed data as a List construct */
places = placeJsonParser.parse(jObject);

}catch(Exception e){
Log.d("Exception",e.toString());
}
return places;
}

// Executed after the complete execution of doInBackground() method
@Override
protected void onPostExecute(List<HashMap<String,String>> list){

// Clears all the existing markers
mGoogleMap.clear();

for(int i=0;i <list.size();i++){

// Creating a marker
MarkerOptions markerOptions = new MarkerOptions();

// Getting a place from the places list
HashMap<String, String> hmPlace = list.get(i);

// Getting latitude of the place
double lat = Double.parseDouble(hmPlace.get("lat"));

// Getting longitude of the place
double lng = Double.parseDouble(hmPlace.get("lng"));

// Getting name
String name = hmPlace.get("place_name");

// Getting vicinity
String vicinity = hmPlace.get("vicinity");

LatLng latLng = new LatLng(lat, lng);

// Setting the position for the marker
markerOptions.position(latLng);

// Setting the title for the marker.
//This will be displayed on taping the marker
markerOptions.title(name + " : " + vicinity);

// Placing a marker on the touched position
Marker m = mGoogleMap.addMarker(markerOptions);

// Linking Marker id and place reference
mMarkerPlaceLink.put(m.getId(), hmPlace.get("reference"));

}

}

}

@Override
public boolean onCreateOptionsMenu(Menu menu) {
// Inflate the menu; this adds items to the action bar if it is present.
getMenuInflater().inflate(R.menu.main, menu);
return true;
}

@Override
public void onLocationChanged(Location location) {
mLatitude = location.getLatitude();
mLongitude = location.getLongitude();
LatLng latLng = new LatLng(mLatitude, mLongitude);

mGoogleMap.moveCamera(CameraUpdateFactory.newLatLng(latLng));
mGoogleMap.animateCamera(CameraUpdateFactory.zoomTo(12));

}

@Override
public void onProviderDisabled(String provider) {
// TODO Auto-generated method stub

}

@Override
public void onProviderEnabled(String provider) {
// TODO Auto-generated method stub

}

@Override
public void onStatusChanged(String provider, int status, Bundle extras) {
// TODO Auto-generated method stub
}
}

1.) PlaceDetailsActivity.java

package com.mapv2.demo;

import java.io.BufferedReader;
import java.io.IOException;
import java.io.InputStream;
import java.io.InputStreamReader;
import java.net.HttpURLConnection;
import java.net.URL;
import java.util.HashMap;

import org.json.JSONObject;

import android.app.Activity;
import android.os.AsyncTask;
import android.os.Bundle;
import android.util.Log;
import android.webkit.WebView;

public class PlaceDetailsActivity extends Activity {
WebView mWvPlaceDetails;

protected void onCreate(Bundle savedInstanceState) {

super.onCreate(savedInstanceState);
setContentView(R.layout.activity_place_details);

// Getting reference to WebView ( wv_place_details ) of the layout activity_place_details
mWvPlaceDetails = (WebView) findViewById(R.id.wv_place_details);

mWvPlaceDetails.getSettings().setUseWideViewPort(false);

// Getting place reference from the map
String reference = getIntent().getStringExtra("reference");

StringBuilder sb = new StringBuilder("https://maps.googleapis.com/maps/api/place/details/json?");
sb.append("reference="+reference);
sb.append("&amp;sensor=true");
sb.append("&amp;key=AIzaSyCfdXATlz7jtM6MEvy9Xh_3_g_Ivc5ysXE");

// Creating a new non-ui thread task to download Google place details
PlacesTask placesTask = new PlacesTask();

// Invokes the "doInBackground()" method of the class PlaceTask
placesTask.execute(sb.toString());

};

/** A method to download json data from url */
private String downloadUrl(String strUrl) throws IOException{
String data = "";
InputStream iStream = null;
HttpURLConnection urlConnection = null;
try{
URL url = new URL(strUrl);

// Creating an http connection to communicate with url
urlConnection = (HttpURLConnection) url.openConnection();

// Connecting to url
urlConnection.connect();

// Reading data from url
iStream = urlConnection.getInputStream();

BufferedReader br = new BufferedReader(new InputStreamReader(iStream));

StringBuffer sb = new StringBuffer();

String line = "";
while( ( line = br.readLine()) != null){
sb.append(line);
}

data = sb.toString();
br.close();

}catch(Exception e){
Log.d("Exception while downloading url", e.toString());
}finally{
iStream.close();
urlConnection.disconnect();
}

return data;
}

/** A class, to download Google Place Details */
private class PlacesTask extends AsyncTask&lt;String, Integer, String&gt;{

String data = null;

// Invoked by execute() method of this object
@Override
protected String doInBackground(String... url) {
try{
data = downloadUrl(url[0]);
}catch(Exception e){
Log.d("Background Task",e.toString());
}
return data;
}

// Executed after the complete execution of doInBackground() method
@Override
protected void onPostExecute(String result){
ParserTask parserTask = new ParserTask();

// Start parsing the Google place details in JSON format
// Invokes the "doInBackground()" method of the class ParseTask
parserTask.execute(result);
}
}

/** A class to parse the Google Place Details in JSON format */
private class ParserTask extends AsyncTask&lt;String, Integer, HashMap&lt;String,String&gt;&gt;{

JSONObject jObject;

// Invoked by execute() method of this object
@Override
protected HashMap&lt;String,String&gt; doInBackground(String... jsonData) {

HashMap&lt;String, String&gt; hPlaceDetails = null;
PlaceDetailsJSONParser placeDetailsJsonParser = new PlaceDetailsJSONParser();

try{
jObject = new JSONObject(jsonData[0]);

// Start parsing Google place details in JSON format
hPlaceDetails = placeDetailsJsonParser.parse(jObject);

}catch(Exception e){
Log.d("Exception",e.toString());
}
return hPlaceDetails;
}

// Executed after the complete execution of doInBackground() method
@Override
protected void onPostExecute(HashMap&lt;String,String&gt; hPlaceDetails){

String name = hPlaceDetails.get("name");
String icon = hPlaceDetails.get("icon");
String vicinity = hPlaceDetails.get("vicinity");
String lat = hPlaceDetails.get("lat");
String lng = hPlaceDetails.get("lng");
String formatted_address = hPlaceDetails.get("formatted_address");
String formatted_phone = hPlaceDetails.get("formatted_phone");
String website = hPlaceDetails.get("website");
String rating = hPlaceDetails.get("rating");
String international_phone_number = hPlaceDetails.get("international_phone_number");
String url = hPlaceDetails.get("url");

String mimeType = "text/html";
String encoding = "utf-8";

String data = ""+ "<img style="float: left;" src="+icon+" alt="" />

<center>"+name+"</center>" +
"<br style="clear: both;" />" +
"

<hr />

"+
"

Vicinity : " + vicinity + "

" +
"

Location : " + lat + "," + lng + "

" +
"

Address : " + formatted_address + "

" +
"

Phone : " + formatted_phone + "

" +
"

Website : " + website + "

" +
"

Rating : " + rating + "

" +
"

International Phone : " + international_phone_number + "

" +
"

URL : <a href="&quot; + url + &quot;">" + url + "</a>

" +
"

";

&nbsp;

// Setting the data in WebView
mWvPlaceDetails.loadDataWithBaseURL("", data, mimeType, encoding, "");
}
}
}

2.) PlaceDetailsJSONParser.java

package com.mapv2.demo;

import java.util.HashMap;

import org.json.JSONException;
import org.json.JSONObject;

public class PlaceDetailsJSONParser {

/** Receives a JSONObject and returns a list */
public HashMap&lt;String,String&gt; parse(JSONObject jObject){

JSONObject jPlaceDetails = null;
try {
/** Retrieves all the elements in the 'places' array */
jPlaceDetails = jObject.getJSONObject("result");
} catch (JSONException e) {
e.printStackTrace();
}
/** Invoking getPlaces with the array of json object
* where each json object represent a place
*/
return getPlaceDetails(jPlaceDetails);
}

/** Parsing the Place Detai12ls Object object */
private HashMap&lt;String, String&gt; getPlaceDetails(JSONObject jPlaceDetails){

HashMap&lt;String, String&gt; hPlaceDetails = new HashMap&lt;String, String&gt;();

String name = "-NA-";
String icon = "-NA-";
String vicinity="-NA-";
String latitude="";
String longitude="";
String formatted_address="-NA-";
String formatted_phone="-NA-";
String website="-NA-";
String rating="-NA-";
String international_phone_number="-NA-";
String url="-NA-";

try {
// Extracting Place name, if available
if(!jPlaceDetails.isNull("name")){
name = jPlaceDetails.getString("name");
}

// Extracting Icon, if available
if(!jPlaceDetails.isNull("icon")){
icon = jPlaceDetails.getString("icon");
}

// Extracting Place Vicinity, if available
if(!jPlaceDetails.isNull("vicinity")){
vicinity = jPlaceDetails.getString("vicinity");
}

// Extracting Place formatted_address, if available
if(!jPlaceDetails.isNull("formatted_address")){
formatted_address = jPlaceDetails.getString("formatted_address");
}

// Extracting Place formatted_phone, if available
if(!jPlaceDetails.isNull("formatted_phone_number")){
formatted_phone = jPlaceDetails.getString("formatted_phone_number");
}

// Extracting website, if available
if(!jPlaceDetails.isNull("website")){
website = jPlaceDetails.getString("website");
}

// Extracting rating, if available
if(!jPlaceDetails.isNull("rating")){
rating = jPlaceDetails.getString("rating");
}

// Extracting rating, if available
if(!jPlaceDetails.isNull("international_phone_number")){
international_phone_number = jPlaceDetails.getString("international_phone_number");
}

// Extracting url, if available
if(!jPlaceDetails.isNull("url")){
url = jPlaceDetails.getString("url");
}

latitude = jPlaceDetails.getJSONObject("geometry").getJSONObject("location").getString("lat");
longitude = jPlaceDetails.getJSONObject("geometry").getJSONObject("location").getString("lng");

hPlaceDetails.put("name", name);
hPlaceDetails.put("icon", icon);
hPlaceDetails.put("vicinity", vicinity);
hPlaceDetails.put("lat", latitude);
hPlaceDetails.put("lng", longitude);
hPlaceDetails.put("formatted_address", formatted_address);
hPlaceDetails.put("formatted_phone", formatted_phone);
hPlaceDetails.put("website", website);
hPlaceDetails.put("rating", rating);
hPlaceDetails.put("international_phone_number", international_phone_number);
hPlaceDetails.put("url", url);

} catch (JSONException e) {
e.printStackTrace();
}

return hPlaceDetails;
}
}

3.) PlaceJSONParser.java

package com.mapv2.demo;

import java.util.ArrayList;
import java.util.HashMap;
import java.util.List;

import org.json.JSONArray;
import org.json.JSONException;
import org.json.JSONObject;

public class PlaceJSONParser {

/** Receives a JSONObject and returns a list */
public List<HashMap<String,String>> parse(JSONObject jObject){

JSONArray jPlaces = null;
try {
/** Retrieves all the elements in the 'places' array */
jPlaces = jObject.getJSONArray("results");
} catch (JSONException e) {
e.printStackTrace();
}
/** Invoking getPlaces with the array of json object
* where each json object represent a place
*/
return getPlaces(jPlaces);
}

private List<HashMap<String, String>> getPlaces(JSONArray jPlaces){
int placesCount = jPlaces.length();
List<HashMap<String, String>> placesList = new ArrayList<HashMap<String,String>>();
HashMap<String, String> place = null;

/** Taking each place, parses and adds to list object */
for(int i=0; i <placesCount;i++){
try {
/** Call getPlace with place JSON object to parse the place */
place = getPlace((JSONObject)jPlaces.get(i));
placesList.add(place);

} catch (JSONException e) {
e.printStackTrace();
}
}

return placesList;
}

/** Parsing the Place JSON object */
private HashMap<String, String> getPlace(JSONObject jPlace){

HashMap<String, String> place = new HashMap<String, String>();
String placeName = "-NA-";
String vicinity="-NA-";
String latitude="";
String longitude="";
String reference="";

try {
// Extracting Place name, if available
if(!jPlace.isNull("name")){
placeName = jPlace.getString("name");
}

// Extracting Place Vicinity, if available
if(!jPlace.isNull("vicinity")){
vicinity = jPlace.getString("vicinity");
}

latitude = jPlace.getJSONObject("geometry").getJSONObject("location").getString("lat");
longitude = jPlace.getJSONObject("geometry").getJSONObject("location").getString("lng");
reference = jPlace.getString("reference");

place.put("place_name", placeName);
place.put("vicinity", vicinity);
place.put("lat", latitude);
place.put("lng", longitude);
place.put("reference", reference);

} catch (JSONException e) {
e.printStackTrace();
}
return place;
}
}

Step 6 :- Run Code.

admin@androidtrainee

Related Posts

1 Comment

  1. chaitali Reply to chaitali
    April 5, 2016 at 12:52 pm

    please provide the full source code. for Showing nearby places and place details using Google Places API and Google Maps Android API V2….

Leave a Reply

© Copyright 2014. Theme by BloomPixel.
